Technical Data

Capacity	Capacity	Stroke	Model	Effective area	Oil cap.	Closed height	Wt. (Approx.)
(ton)	(kN)	(mm)	Model	(cm2)	(cc)	(mm)	(kg)
10	111	30	TSL 10-30	15.9	48	90	2.3
20	218	50	TSL 20-50	31.2	160	115	4.9
30	309	50	TSL 30-50	44.2	221	120	6
50	550	60	TSL 50-60	78.5	471	125	11
75	792	60	TSL 75-60	113.1	679	145	18.4
100	1077	60	TSL 100-60	153.9	925	150	23.6
150	1589	60	TSL 150-60	227	1362	165	43
200	2199	60	TSL 200-60	314.2	1885	200	66
